Mule 4: Batch vs Foreach vs Streaming — How to Choose

Every integration eventually has to loop over a collection — a list of orders, a file of customers, a query result. Mule 4 gives you three fundamentally different tools for it, and they are not interchangeable. The whole choice comes down to three questions: how much data, how much fault-tolerance, and do you need per-record error isolation?

TL;DR — The 10-Second Answer

Three tools, three jobs. Match the shape of your work to one of these and you’ll rarely go wrong.

01 · foreach — Sequential, In-Memory Iteration

The foreach scope iterates a collection one element at a time, keeping the whole collection in memory. parallel-foreach does the same across several threads. Both are the right call when the collection is modest and you don’t need sophisticated error recovery.

<!-- one element at a time, held in heap -->
<foreach collection="#[payload]">
  <flow-ref name="processOne"/>
</foreach>

The catch: foreach loads the entire collection into the heap, and by default an unhandled error in any iteration stops the loop. That’s fine for a few hundred records — fatal for a few million.

02 · Streaming — Constant-Memory Transforms

When the job is a pure transformation — read a big payload, reshape it, write it out, with no per-record branching or external calls — DataWeave streaming processes it in constant memory. Records flow through without the whole document ever being materialized at once.

// deferred + a streamed source: never fully in heap
%dw 2.0
output application/json deferred=true
---
payload map (row) -> {
  id:   row.customerId,
  name: upper(row.fullName)
}

This is how you convert a 10 GB CSV to JSON without an out-of-memory crash. But streaming is forward-only and single-pass: you can’t retry an individual record, branch failures to a dead-letter table, or resume after a crash. It’s a transform, not a workflow.

03 · Batch — Volume With a Workflow

The Batch module is the heavyweight: it splits the incoming collection into individual records on a persistent on-disk queue, processes them in parallel blocks, isolates errors per record, and resumes automatically if the runtime crashes mid-job. It exists for exactly the case the other two can’t handle — high volume with a real workflow around each record.

<batch:job jobName="customerEtl" blockSize="100">
  <batch:process-records>
    <batch:step name="validate">          <!-- per record -->
      <!-- transform, call APIs, raise errors -->
    </batch:step>
    <batch:step name="load" acceptPolicy="NO_FAILURES">
      <batch:aggregator size="100">
        <!-- bulk commit 100 at a time -->
      </batch:aggregator>
    </batch:step>
  </batch:process-records>
  <batch:on-complete> <!-- stats only --> </batch:on-complete>
</batch:job>

The overhead — queues, blocks, three phases — is real, which is exactly why you don’t use it for a list of ten. But for an ETL sync, a bulk Salesforce upsert, or a nightly warehouse load, it’s the only tool that gives you parallelism, per-record error isolation, and crash recovery together.

Compare — The Signals, Side by Side

FAQ — Common Questions

Is parallel-foreach the same as the Batch module?

No. parallel-foreach runs iterations concurrently but holds the whole collection in memory and has no per-record error isolation or crash recovery. The Batch module chunks records onto a persistent queue, isolates failures per record, and resumes after a crash. Use parallel-foreach to speed up a modest I/O-bound loop; use Batch for fault-tolerant volume.

When is streaming better than the Batch module?

When the work is a pure transformation — reshaping a large payload from one format or shape to another with no per-record external calls, branching, or retry. Streaming gives you constant memory and is simpler. The moment you need per-record error handling or resumability, switch to Batch.

What record count means I should switch from foreach to Batch?

There’s no hard number, but a practical line is a few thousand records — or any point where the collection won’t comfortably fit in heap, a single bad record shouldn’t fail the whole run, or the job needs to survive a restart. Hit any of those and reach for Batch.

Does the Batch module work the same on CloudHub 2.0?

Mostly, with one caveat: batch resumability relies on durable local storage, and CloudHub 2.0 replica storage is ephemeral — a replica restart can lose in-flight batch state. For long, critical jobs there, design for re-runnability (track a watermark, make the load an idempotent upsert) rather than relying on automatic resume.
